| Type: |
HF Receiver |
| Frequency Range: |
550kHz to 30MHz in 4 Bands
Band A: 0.55-1.6 MHz
Band B: 1.6-4.8 MHz
Band C: 4.8-14.5 MHz
Band D: 10.5-30 MHz |
| Modes: |
AM/SSB/CW |
| Sensitivity: |
Band A, B & C: <6 dB (10 dB S/N)
Band D: <18 dB (13 MHz), <10 dB (28 MHz) |
| Selectivity: |
10 KHz (-50 dB |
| Image rejection: |
N/A |
| Voltage: |
Mains: 110-120 / 220-240 VAC |
| Current Drain: |
45 W |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
381 x 178 x 254 mm (15 x 7 x 10 onches) |
| Weight: |
8.53 Kg (18.81 lb) |
| Manufactured: |
Japan: 1968-1969 |
| Other: |
Band Spread on Amateur Bands
Valves |
| Related Documents: |
User Manual (2.04 MB)
Schematic (29.2 KB) |
